FORCE FEED LUBRICATOR
The “VERTEX” force feed lubricators are precision metering pumps operating within steel fabricated reservoirs. Which contain lubricant (either mineral oil base or synthetic) to be pumped; each pumping unit with its sight feed supplies a single point of lubrication. Lubricator may be furnished in single or multi-feed units for any number of points of lubricator in a wide choice of adjustable feeds, single or multi-compartment reservoirs, various drives and arrangements for a broad range of lubricants, viscosities and desired line pressure.
“VERTEX” lubricator pumping unit is fitted with an integrate sight unit showing the flow of lubricant in to each line.
FEATURES:-
GENERAL PURPOSE LUBRICATION – Automatic, precision metering for all types of machine.
TYPE PUMPING UNIT – Clear-view, sight unit functions of atmospheric pressure, shows amount of lubricant being pumped. Equipped with inlet strainer.
NO. OF FEED – 1 to 16 per Lubricator standard.
DISPLACEMENT – OUTPUT – 9 to 12 drops per stroke with ½” plunger, Adjustable from 0 to 0.28 cc/stroke/element.
AVAILABLE DRIVES – Direct rotory (internal reduction 60:1, 120:1, 11:2)
RESERVOIRS – Single compartment, sheet metal available – 3ltr, 4.8ltr, 6ltr, 8.5ltr, 10.8ltr, 12ltr.
FEED REGULATOR – External screw type precisely adjustable while idle or in operation.
REMOVABLE PUMPING UNIT – Self contained, all unit interchangeable (For same working pressure) remove two screws and lift out.
HAND CRANK – Optional if required convenient for rapid priming of lines before startup.
LEGEND
REPLACEMENT – “VERTEX” can be replaced all world leading manufacturer of Force Feed Lubricators.
ACCESSORIES AVAILABLE –
Angle check valve
Straight check valve
LOL switch
Timer switch
Banjo connector
Hand priming arrangement
Rachet arrangement
Motor driven lubricators
|
